Specifications
- Manufacturer: Harley-Davidson
- Model: Low Rider® ST Tobacco Fade
- Year: 2024
- Type: Cruiser
- Length: 2,365 mm
- Seat Height, Unladen: 720 mm
- Ground Clearance: 150 mm
- Rake: 28
- Trail: 145 mm
- Wheelbase: 1,615 mm
- Tire, Type: Michelin™ Scorcher 31, front and rear
- Tires, Front Specification: 110/90B19,62H,BW
- Tires, Rear Specification: 180/70B16,77H,BW
- Fuel Capacity: 18.9 l
- Oil Capacity (w/filter): 4.7 l
- Weight, As Shipped: 315 kg
- Weight, In Running Order: 327 kg
- Luggage Capacity -Volume: 0.05 m3
- Engine: Milwaukee-Eight™ 117
- Bore: 103.5 mm
- Stroke: 114.3 mm
- Displacement: 1,923 cc
- Compression Ratio: 10.2:1
- Fuel System: Electronic Sequential Port Fuel Injection (ESPFI)
- Exhaust: 2-into-2 offset shotgun; catalyst in muffler
- Engine Torque Testing Method: J1349
- Engine Torque: 169 Nm
- Engine Torque (rpm): 3,500
- Horsepower: 103 HP / 77 kW @ 4750 rpm
- Lean Angle, Right (deg.): 31.3
- Lean Angle, Left (deg.): 31.3
- Fuel Economy Testing Method: Estimated City/Hwy
- Fuel Economy: 5 l/100 km
- Primary Drive: Chain, 34/46 ratio
- Gear Ratios (overall) 1st: 9.311
- Gear Ratios (overall) 2nd: 6.454
- Gear Ratios (overall) 3rd: 4.793
- Gear Ratios (overall) 4th: 3.882
- Gear Ratios (overall) 5th: 3.307
- Gear Ratios (overall) 6th: 2.79
- Front Fork: Single cartridge 43 mm inverted with aluminum fork triple clamps; single rate spring
- Rear Shocks: Hidden, free piston, coil-over monoshock; 56 mm stroke; hydraulic preload adjustment
- Wheels, Front Type: Dark bronze, Radiate cast aluminum wheel
- Wheels, Rear Type: Dark bronze, Radiate cast aluminum wheel
- Brakes, Caliper Type: 4-piston fixed front and 2-piston floating rear
- Brakes, Rotor Type: Front and rear black, Split 7-spoke floating rotors
- Lights (as per country regulation), Headlamp, Tail/Stop/Front Signal Lights: All LED, low beam, high beam and signature position lamp; LED Zeppelin tail lamp; Incandescent bullet turn signals
- Gauges: 2.14 inch viewable area LCD display with speedometer, gear, odometer, fuel level, clock, trip, range and tachometer indication
- Anti-lock Brake System (ABS): Included
- Traction Control System (TCS): Included
