2024 Harley-Davidson Low Rider® S Vivid Black

Specifications

  • Manufacturer: Harley-Davidson
  • Model: Low Rider® S Vivid Black
  • Year: 2024
  • Type: Cruiser
  • Length: 2,365 mm
  • Seat Height, Unladen: 710 mm
  • Ground Clearance: 145 mm
  • Rake: 28
  • Trail: 145 mm
  • Wheelbase: 1,615 mm
  • Tire, Type: Michelin™ Scorcher 31, front and rear
  • Tires, Front Specification: 110/90B19,62H,BW
  • Tires, Rear Specification: 180/70B16,77H,BW
  • Fuel Capacity: 18.9 l
  • Oil Capacity (w/filter): 4.7 l
  • Weight, As Shipped: 295 kg
  • Weight, In Running Order: 308 kg
  • Engine: Milwaukee-Eight™ 117
  • Bore: 103.5 mm
  • Stroke: 114.3 mm
  • Displacement: 1,923 cc
  • Compression Ratio: 10.2:1
  • Fuel System: Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust: 2-into-2 offset shotgun; catalyst in muffler
  • Engine Torque Testing Method: J1349
  • Engine Torque: 169 Nm
  • Engine Torque (rpm): 3,500
  • Horsepower: 103 HP / 77 kW @ 4750 rpm
  • Lean Angle, Right (deg.): 31.3
  • Lean Angle, Left (deg.): 31.3
  • Fuel Economy Testing Method: Estimated City/Hwy
  • Fuel Economy: 5 l/100 km
  • Primary Drive: Chain, 34/46 ratio
  • Gear Ratios (overall) 1st: 9.311
  • Gear Ratios (overall) 2nd: 6.454
  • Gear Ratios (overall) 3rd: 4.793
  • Gear Ratios (overall) 4th: 3.882
  • Gear Ratios (overall) 5th: 3.307
  • Gear Ratios (overall) 6th: 2.79
  • Front Fork: Single cartridge 43 mm inverted with aluminum fork triple clamps; triple rate spring
  • Rear Shocks: Hidden, free piston, coil-over monoshock; 56 mm stroke; hydraulic preload adjustment
  • Wheels, Front Type: Dark bronze, Radiate cast aluminum wheel
  • Wheels, Rear Type: Dark bronze, Radiate cast aluminum wheel
  • Brakes, Caliper Type: 4-piston fixed front and 2-piston floating rear
  • Brakes, Rotor Type: Front and rear black, Split 7-spoke floating rotors
  • Lights (as per country regulation), Headlamp, Tail/Stop/Front Signal Lights: All LED, low beam, high beam and signature position lamp; LED Zeppelin tail lamp; Incandescent bullet turn signals
  • Gauges: 4-inch analog tachometer with digital speedometer, gear, odometer, fuel level, clock, trip and range indication
  • Anti-lock Brake System (ABS): Included
  • Traction Control System (TCS): Included
